The 241kWh Liquid-Cooled Energy Storage System is a reliable, efficient solution for industrial and commercial use. It features easy transport, installation, and maintenance, with real-time monitoring and fault logging. The modular design, CTP technology, and parallel expansion provide flexibility, while multiple safety protections ensure reliability. With over 8,000 cycles (70% SOH) and a 15+ year lifespan, it offers long-term performance.
Cell type: Lithium Iron Phosphate Battery
Rated capacity @ BOL : 241kWh @ 25℃，0.5P
Rated power : 100kW
Voltage range : 600~864V
Working temperature range : -20~60℃
Protection registration : IP54
Cycle performance: >8000 Cycles @70%SOH
What is the 241kWh Liquid-Cooled Energy Storage System?
The 241kWh Liquid-Cooled Energy Storage System is an advanced, reliable, and efficient solution designed for industrial and commercial applications. Equipped with lithium iron phosphate (LiFePO4) batteries, it provides a rated capacity of 241kWh at 25°C with a 0.5C discharge rate. The system offers 100kW of rated power and operates within a voltage range of 600-864V, making it compatible with a variety of energy infrastructures.
Features of the 215kWh Liquid-Cooled Energy Storage System
· Wide Operating Temperature Range: -20°C to 60°C, ensuring reliable performance in diverse environmental conditions.
· Liquid Cooling System: Ensures precise temperature control for optimal performance and longevity.
· Cycle Performance: Over 8,000 cycles at 70% state of health (SOH) and a service life exceeding 15 years (one charge per day).
· Compact Design: The system has a cabinet size of 1400mm*1300mm*2200mm.
· Safety Features: Multi-level battery protection, perfluoroacetone fire extinguishing for fire safety, and IP54 protection.
· Corrosion Resistance: Rated C3, with operation in humidity ranges of 0-95% (non-condensing).
· Certifications: CE, UN38.3, MSDS, and 3C certified for quality and safety compliance.
· Communication: Ethernet communication, supporting grid frequencies from 45-55Hz with a wiring method of three-phase four-wire + PE, and operates within a power grid voltage range of 360~440V.
Applications of the 241kWh Liquid-Cooled Energy Storage System
This energy storage system is ideal for industrial and commercial applications where efficient, reliable, and scalable energy storage is needed. It is suitable for use in diverse energy infrastructures, including renewable energy integration, backup power systems, and load leveling.
Price of the 241kWh Liquid-Cooled Energy Storage System
The price of the 241kWh Liquid-Cooled Energy Storage System is based on EXW (Ex Works) terms and may vary depending on the supplier, quantity, and market conditions.You may need to request a quote from a reputable energy storage system supplier to get the most accurate pricing. Please note that the final costs may vary based on fluctuations in raw material prices and exchange rates.
If you are looking for 241kWh Liquid-Cooled Energy Storage System and want to know more about the technical information, please feel free to contact Dagong ESS.
| Property | Value |
|---|---|
| Product Type | DHYL241kWh-100kW-2h |
| Cell Type | Lithium Iron Phosphate Battery |
| Rated Capacity @ BOL | 241kWh @ 25℃，0.5P |
| Rated Power | 100kW |
| Voltage Range | 600~864V |
| Working Temperature Range | -20~60℃ |
| Weight | ≤3000kg |
| Cooling Method | Liquid-cooling system |
| Fire Safety Configuration | Perfluoroacetone fire extinguishing |
| Protection Registration | IP54 |
| Anti-Corrosion Registration | C3 |
| Working Humidity Range | 0~95%(non-condensing) |
| Cabinet Size (L * W * H) | 1400*1300*2200mm |
| Maximum Working Altitude | 3000m |
| Communication Method | Ethernet |
| Voltage Range of Power Grid | 360~440V |
| Wiring Method | Three phase four wire+PE |
| Grid Frequency Range | 45~55Hz |
